技嘉GA-X99-Gaming G1 WIFI主板使用说明书pdf格式

技嘉GA-X99-Gaming G1 wifi支持全新一代Intel® Haswell-E处理器，杀手E2200专业游戏网卡，独立左右声道PCB分层设计。以下文档是技嘉GA-X99-Gaming G1 WIFI使用手册，有需要的朋友可立即下载此文档。

温馨提示：

本文档为PDF格式文档，因此需确保在阅读之前你已经安装了pdf阅读器，如果尚未安装阅读器，建议下载福昕pdf阅读器或其他PDF阅读器，进行安装后阅读。

技嘉GA-X99-Gaming G1 WIFI使用手册目录

清点配件 .......................................................................................................................6

选购配件 .......................................................................................................................6

GA-X99-Gaming G1 WIFI主板配置图 ..........................................................................7

GA-X99-Gaming G1 WIFI主板功能框图 .....................................................................8

第一章 硬件安装 .......................................................................................................9

1-1  安装前的注意事项 .........................................................................................9

1-2  网卡驱动程序下载 .......................................................................................10

1-3  产品规格 .........................................................................................................11

1-4  安装中央处理器及散热风扇 .....................................................................14

1-4-1  安装中央处理器(CPU) .......................................................................................14

1-4-2  安装散热风扇 .....................................................................................................16

1-5  安装内存条 ....................................................................................................17

1-5-1  四通道内存技术 .................................................................................................17

1-5-2  安装内存条 ..........................................................................................................18

1-6  安装扩展卡 ....................................................................................................19

1-7  构建AMD CrossFire ™ /NVIDIA ® SLI ™ 系统 .......................................................20

1-8  后方设备插座介绍 .......................................................................................22

1-9  安装后方I/O设备铁片 ..................................................................................24

1-10 内建按钮及切换器 .......................................................................................25

1-11 更换音频放大器 ...........................................................................................27

1-12 插座及跳线介绍 ...........................................................................................28

第二章 BIOS 程序设置 ............................................................................................39

2-1  开机画面 ........................................................................................................40

2-2  BIOS设定程序主画面 ...................................................................................41

2-3  M.I.T. (频率/电压控制) ..................................................................................44

2-4  System Information (系统信息) ......................................................................56

2-5  BIOS Features (BIOS功能设定) .....................................................................57

2-6  Peripherals (集成外设) ...................................................................................60

2-7  Chipset (芯片组设定) ....................................................................................62

2-8  Power Management (省电功能设定) ............................................................65

2-9  Save & Exit (储存设定值并结束设定程序) ...............................................67

第三章 构建SATA硬盘 ............................................................................................69

3-1  设定SATA控制器模式 ..................................................................................69

3-2  安装SATA RAID/AHCI驱动程序及操作系统 ..............................................81

第四章 驱动程序安装 ............................................................................................85

4-1  Chipset Drivers (芯片组驱动程序) ...............................................................85

4-2  Application Software (软件应用程序) ...........................................................86

4-3  Information (信息清单) ...................................................................................86

第五章 独特功能介绍 ............................................................................................87

5-1  BIOS更新方法介绍 .......................................................................................87

5-1-1  如何使用Q-Flash (BIOS 快速刷新)更新BIOS .................................................87

5-1-2  如何使用@BIOS更新BIOS ................................................................................90

5-1-3  如何执行Q-Flash Plus .........................................................................................91

5-2  APP Center (应用中心) ..................................................................................92

5-2-1  EasyTune................................................................................................................93

5-2-2  System Information Viewer .....................................................................................94

5-2-3  EZ Setup .................................................................................................................95

5-2-4  Fast Boot ................................................................................................................98

5-2-5  Smart TimeLock ......................................................................................................99

5-2-6  Smart Recovery 2 (智能恢复2) ..........................................................................100

5-2-7  USB Blocker .........................................................................................................102

5-2-8  Ambient LED ........................................................................................................103

5-2-9  V-Tuner .................................................................................................................104

5-2-10 Smart Switch ........................................................................................................105

5-2-11 Cloud Station Server ............................................................................................106

5-2-12 Game Controller ...................................................................................................112

第六章 附录 ............................................................................................................113

6-1  Qualcomm ® Atheros Killer Network Manager ..................................................113

6-2  音频输入/输出设定介绍 ............................................................................114

6-2-1  2 / 5.1 声道介绍 .................................................................................................114

6-2-2  Creative软件套件 ...............................................................................................114

6-2-3  S/PDIF输出设定 ................................................................................................118

6-2-4  录音设备设定 ...................................................................................................119

6-2-5  录音机使用介绍 ...............................................................................................121

6-3  疑难排解 ......................................................................................................122

6-3-1  问题集 ................................................................................................................122

6-3-2  故障排除 ............................................................................................................123

6-4  除错灯号代码说明 .....................................................................................125

管理声明 ................................................................................................................129

技嘉主板售后服务及质量保证卡 .....................................................................134

技嘉科技全球服务网...........................................................................................135

技嘉GA-X99-Gaming G1 WIFI主板配置图

技嘉GA-X99-Gaming G1 WIFI规格参数

中央处理器(CPU)

支持LGA2011-3插槽处理器：Intel® Core™ i7处理器

L3高速缓存取决于CPU

芯片组

Intel® X99 高速芯片组

内存

8个DDR4 DIMM插槽，最高支持到64 GB

* 由于Windows 32-bit操作系统的限制，若安装超过4 GB容量内存时，实际上显示之内存容量将少于实际安装的内存容量。

支持4信道内存技术

支持DDR4 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz

支持non-ECC内存

支持Extreme Memory Profile (XMP)内存

支持RDIMM 1Rx8内存 (non-ECC模式运作)

音效

内建Creative® Sound Core 3D芯片

支持Sound Blaster Recon3Di

内建TI Burr Brown® OPA2134音效放大器芯片

支持High Definition Audio

支持2/5.1声道

支持S/PDIF输出

网络

内建Qualcomm® Atheros Killer E2201网络芯片(10/100/1000 Mbit)(LAN1)

内建Intel® GbE 网络芯片(10/100/1000 Mbit) (LAN2)
