TL-TR861 5200L配置详细说明书pdf格式

第1章详细配置指南简介.........................................................................................1

1.1本书约定.....................................................................................................................1

1.2本书章节安排..............................................................................................................1

第2章产品概述........................................................................................................2

2.1产品简介.....................................................................................................................2

2.2主要特性.....................................................................................................................2

第3章硬件描述........................................................................................................3

3.1外观介绍.....................................................................................................................3

3.2移动电源模式..............................................................................................................4

3.3硬件重置.....................................................................................................................4

3.4复位............................................................................................................................5

3.5系统需求.....................................................................................................................5

3.6安装环境.....................................................................................................................5

第4章快速安装指南.................................................................................................6

4.1安装无线数据终端.......................................................................................................6

4.2建立正确的IP设置.......................................................................................................8

4.2.1Windows7下设置IP.....................................................................................8

4.2.2WindowsXP下设置IP...................................................................................9

4.3连接到无线网络........................................................................................................10

4.3.1Windows7下无线网络连接........................................................................10

4.3.2WindowsXP下无线网络连接......................................................................11

4.3.3苹果iOS下无线网络连接.............................................................................12

4.3.4Android下无线网络连接..............................................................................14

4.4设置无线数据终端.....................................................................................................15

4.5重新连接到无线数据终端..........................................................................................18

4.5.1Windows7下无线网络连接........................................................................18

4.5.2WindowsXP下无线网络连接......................................................................19

4.5.3苹果iOS下无线网络连接.............................................................................20

4.5.4Android下无线网络连接..............................................................................21

第5章配置指南......................................................................................................23

5.1登录配置界面............................................................................................................23

5.2连接状态...................................................................................................................23

5.3设置向导...................................................................................................................24

5.4短信..........................................................................................................................24

5.4.1书写短信.....................................................................................................24

5.4.2收件箱.........................................................................................................25

5.4.3发件箱.........................................................................................................25

5.4.4草稿箱.........................................................................................................26

5.4.5短信设置.....................................................................................................27

5.5高级设置...................................................................................................................28

5.5.1拨号设置.....................................................................................................28

5.5.2无线设置.....................................................................................................30

5.5.3DHCP服务..................................................................................................32

5.5.4系统工具.....................................................................................................34

附录AFAQ............................................................................................................38

附录BIE浏览器设置..............................................................................................41

附录C无线MAC地址查询......................................................................................43

附录D规格参数.....................................................................................................51

网络类型

3G：HSPA+，HSPA，UMTS

2G：GSM，GPRS，EDGE

WiFi：IEEE 802.11n/g/b

频率范围

GSM/GPRS/EDGE：900/1800MHz

HSPA+/HSUPA/HSDPA/UMTS：2100MHz

WiFi：2.4GHz

3G传输速率

下行最高21.6Mbps

上行最高5.76Mbps

WiFi传输速率

最高可达72Mbps

接口类型

MicroUSB 2.0接口

标准USB 2.0接口

标准SIM卡插槽

Micro SD卡插槽

电源

直流电源5V/1A

按钮

电源开关

Reset复位按钮

天线

内置全向天线

存储卡

支持Micro SD卡，最高可支持32GB

尺寸

100mm×44.3mm×28.5mm（L x W x H）
